Description
CTO HPE ProLiant DL360 Gen10 Plus 10 bay SFF server
This is factory configured CTO model, part number P28948-B21
Detailed list of part numbers is below
Further customization is available, please inquire
Warranty: 3-year parts, 3-year labor, 3-year onsite support with next business day response from HPE
Chassis:
1U Server
2x CPU platform
2x CPUs installed, additional CPU configs are available, please inquire
10 bays SFF (2.5") SATA/SAS
CPU:
2x Intel Xeon Gold 6354 3.0 - 3.6GHz 18 core 39MB L3 205W installed
2x High Performance Heatsink installed
Additional CPU config is available
RAM:
2x 32GB DDR4 Registered ECC 3200MHz Module (additional RAM configs are available)
32x RAM slots on motherboard
Up to 8TB of RAM per server
RAID:
Smart Array P408i-a 12Gb/s SAS/SATA/HBA RAID Controller/Adapter
Smart battery is installed
Alternative RAID adapters are available
HDD/SSD:
None included, various sizes and types are available, please inquire
NIC:
Dual Port 10/25Gbe SFP28 QL41232 NIC in OCP3 slot
Additional NICs are available
Fans:
7 high performance hot swappable fans installed
PCI-e slots:
3x PCI-e 4.0 slots x16 (1x FH, 2x LP)
Additional PCI-e slots/risers are available, please inquire
Remote management / iLO5:
Standard
Advanced license is available, please inquire
PSU:
2x 1600W FlexSlot Power supply installed
Rail kit:
Included
Cable management arm:
Not included
Warranty:
3-year parts from HPE
3-year labor from HPE
3-year onsite support with next business day response from HPE
Please contact us with any questions
Detailed list of part:
P28948-B21 HPE DL360 Gen10+ 8SFF NC CTO Svr
P28948-B21#ABA DL360 Gen10 Plus 8SFF CTO Server
P36935-B21 INT Xeon-G 6354 CPU for HPE
P36935-B21#0D1 Factory Integrated
P40007-B21 HPE 32GB 1Rx4 PC4-3200AA-R Smart Kit
P40007-B21#0D1 Factory Integrated
P26427-B21 HPE DL360 Gen10+ 8SFF SAS/SATA BC BP Kit
P26427-B21#0D1 Factory integrated
P26435-B21 HPE DL360 Gen10+ 2SFF SAS/SATA BC Kit
P26435-B21#0D1 Factory integrated
P26471-B21 HPE DL36x Gen10+ LP Riser Kit
P26471-B21#0D1 Factory integrated
P01366-B21 HPE 96W Smart Stg Li-ion Batt 145mm Kit
P01366-B21#0D1 Factory Integrated
P26279-B21 Broadcom MR416i-a Cntrl for HPE Gen10+
P26279-B21#0D1 Factory Integrated
P10118-B21 HPE 10/25GbE 2P SFP28 QL41232 OCP3 Adptr
P10118-B21#0D1 Factory Integrated
P26477-B21 HPE DL36x Gen10+ High Perf Fan Kit
P26477-B21#0D1 Factory integrated
P38997-B21 HPE 1600W FS Plat Ht Plg LH Pwr Sply Kit
P38997-B21#0D1 HPE 1600W II FS Plat HtPlg Pwr Spply Kit
P55882-B21 HPE DL36x G10+ 8SFF SAS/SATA TM Cbl Kit
P55882-B21#0D1 Factory integrated
P55883-B21 HPE DL36x G10+ 2SFF SAS/SATA TM Cbl Kit
P55883-B21#0D1 Factory integrated
867998-B21 HPE 1U Gen10 Bezel Kit
867998-B21#0D1 Factory Integrated
875519-B21 HPE Bezel Lock Kit
875519-B21#0D1 Factory Integrated
P13771-B21 HPE Gen10 Plus TPM BR Module Kit
P13771-B21#0D1 Factory Integrated
P14604-B21 HPE Gen10+ Intrusion Detection Kit
P14604-B21#0D1 Factory Integrated
P26479-B21 HPE DL360 Gen10+ High Perf Heat Sink Kit
P26479-B21#0D1 Factory integrated
P26485-B21 HPE DL300 G10+ 1U SFF Easy Inst Rail Kit
P26485-B21#0D1 Factory integrated
| General Information | |
|---|---|
Vendor |
HPE
|
